At PCIM Expo 2025 in Nuremberg, Germany, Rohde & Schwarz will present its latest portfolio of test and measurement solutions designed for the evolving needs of power electronics development. Visitors to booth 166 in Hall 7 will discover a range of advanced tools specifically engineered to support the analysis and validation of next-generation wide bandgap (WBG) semiconductor technologies such as gallium nitride (GaN) and silicon carbide (SiC).
Caption: The R&S RT-ZISO isolated probing system is the highlight at Rohde & Schwarz’s PCIM 2025 exhibit.
With increasing demands on performance, efficiency, and reliability in sectors like electric mobility, renewable energy systems, and AI-driven data centers, robust testing and characterization have become essential for power engineers. From May 6–8, 2025, Rohde & Schwarz will demonstrate how its instruments enable precise evaluation of high-speed switching behavior, thermal stability, and overall system performance.
Advanced WBG Device Analysis
The centerpiece of the exhibition setup will be the R&S RT-ZISO isolated probing system , a groundbreaking solution tailored for accurate measurements in SiC and GaN-based designs. This high-precision probe delivers unmatched dynamic range, sensitivity, and bandwidth, addressing key challenges in measuring high-voltage switching signals. A live demonstration will illustrate the benefits of using R&S RT-ZISO over traditional single-ended probes when analyzing the switching dynamics of GaN-MosFETs.
Double Pulse Testing Made Reliable
Double pulse testing is vital for assessing the switching characteristics of WBG devices under real-world conditions. In collaboration with PE-Systems GmbH, Rohde & Schwarz will present a highly stable double pulse test configuration utilizing the MXO 5 oscilloscope —featuring eight channels—and the R&S RT-ZISO . At the event, attendees will see this setup in action on 1200 V SiC devices from Wolfspeed, commonly found in automotive traction inverters.
Accelerating Loadjump Testing Through Automation
Traditionally a manual and time-intensive process, loadjump testing can now be fully automated. With software from PE-Systems GmbH, along with the MXO 5 oscilloscope and R&S RT-ZISO , Rohde & Schwarz offers a streamlined solution that significantly cuts testing duration while enabling more detailed data collection across a wide voltage range. At PCIM, the joint solution will be demonstrated on a Monolithic Power Systems Buck converter , covering input voltages from 6V to 60V. Optional integration with temperature control allows for broader environmental condition testing.
Comprehensive Component Characterization
In addition to system-level tests, Rohde & Schwarz will present instruments for detailed component characterization. The R&S LCX LCR meters , equipped with specialized impedance functions, are ideal for evaluating passive components up to 10 MHz. These tools allow engineers to analyze parameters such as voltage-dependent capacitance in multilayer ceramic capacitors (MLCCs), critical elements in power converters.
For deeper impedance spectroscopy, the MFIA impedance analyzer from Zurich Instruments AG—a Rohde & Schwarz subsidiary since 2021—offers precision measurements across a wide impedance range. It supports frequency and time-domain analyses and includes built-in oscilloscope and spectrum analyzer capabilities.
Dr. Philipp Weigell, Vice President of the Industry, Components, Research & University Market Segment at Rohde & Schwarz, commented:
“PCIM provides a crucial platform for us to showcase our innovations in WBG semiconductor testing. As industries strive for higher efficiency and compact power conversion systems—particularly in data centers and e-mobility—precise and reliable test solutions are indispensable. By partnering with leading experts and leveraging our advanced instrumentation, we empower customers to build high-performance, thermally efficient, and dependable power systems.”
Visit Rohde & Schwarz at PCIM Expo 2025 , May 6–8, in Hall 7, Booth 166, to experience these test and measurement solutions firsthand.
For more information about Rohde & Schwarz’s power electronics testing offerings, visit: https://www.rohde-schwarz.com/power-electronics
